Victron 150/85 VE.Can MPPT Charge Controller 48V HV for Residential solar, Commercial and, Off-grid and hybrid

Name: Victron 150/85 VE.Can 48V HV MPPT Charge Controller | Best Price
Brand: victron
SKU: VICTRONS-299-0

Brand victron

Ask about this product

0 /5.0 (0 reviews)

SKU VICTRONS-299-0

Pricing

UGX3,267,000 /Pc

10 available

Minimum order qty 1

QTY

Receive up to 4 quotations from different suppliers of this product

Estimate Shipping Time 1 Days

Inhouse product

Message Seller

Brand victron

Products from this brand

Product spotlights

Highlights: HV configuration. The Victron 150/85 VE.Can MPPT Charge Controller supports low voltage (LV) systems with auto-select for 12V, 24V, and 48V, and manual 36V configuration. Designed for both single-phase and multi-phase solar installations in Uganda, it features adaptive charging algorithms and parallel operation for scalable off-grid and hybrid systems.

Brand	Victron	Model	150/85 VE.Can MPPT Charge Controller
Max PV Input Power	1200	Max Charging Current	85
Nominal Voltage	12/24/48V Auto Select (36V: manual)	Product Weight	MC4 models: 246 x 295 x 103
Communication	VE.Can, VE.Direct and Bluetooth	Efficiency	98
Battery terminals	35mm² / AWG2	Charging Algorithm	multi-stage adaptive (eight preprogrammed algorithms) or user defined algorithm
Humidity	95 %, non-condensing	Max PV Short Circuit Current (per tracker)	70A (max 30A per MC4 conn.)
Max PV Voltage (DC)	150	Programmable Relay	DPST AC rating: 240VAC / 4A DC rating: 4A up to 35VDC, 1A up to 60VDC
Protection	PV reverse polarity / Output short circuit / Over temperature	Protection Category (IP)	IP43 (electronic components), IP22 (connection area)
PV terminals	Three pairs of MC4 connectors (MC4 models)	Remote On/Off	Yes (2 pole connector)
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2	Self-consumption	Less than 35 mA @ 12V / 20 mA @ 48V
SKU	SM-MPP-VIC-00250	Temperature Compensation Range	-16 mV / -32 mV / -64 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Compare With Similar capacity MPPT Charge Controller

Cash on Delivery Available
Free Shipping

0.0

Average Rating

Verified Reviews

Product Questions

Units In Stock

Freelancers

Verified

Verified Solar Installers for this Product

View All

No freelancers found for this skill.

Description

Specs & details

Overview

HV configuration. The Victron 150/85 VE.Can MPPT Charge Controller is engineered for reliable solar power management in Uganda’s diverse energy environments. Supporting low voltage (LV) battery banks with auto-selection for 12V, 24V, and 48V (manual for 36V), this controller is suitable for both single-phase and multi-phase applications. Its advanced MPPT technology ensures high efficiency (up to 98%) in energy conversion, while adaptive multi-stage charging algorithms optimize battery health. The unit allows for parallel operation—up to 25 controllers via VE.Can or 10 via Bluetooth—enabling flexible system expansion. Integrated data communication options (VE.Can, VE.Direct, Bluetooth) and programmable relay functions provide robust system monitoring and control. The controller is protected against PV reverse polarity, output short circuit, and over-temperature, making it suitable for indoor, unconditioned environments across Uganda. Compliance with international safety standards (EN/IEC 62109-1, UL 1741, CSA C22.2) ensures dependable operation in both residential and commercial solar projects.

About this item

SYSTEM TOPOLOGY: HV architecture for compliant solar system design.
MULTI-VOLTAGE SUPPORT: Auto-selects 12V, 24V, or 48V battery banks; manual option for 36V systems.
HIGH CHARGE CURRENT: Delivers up to 85A rated charge current for large-scale solar arrays.
PARALLEL OPERATION: Supports synchronized operation of up to 25 units via VE.Can or 10 via Bluetooth.
ADAPTIVE CHARGING: Features multi-stage, user-configurable charging algorithms for optimal battery performance.
ROBUST PROTECTION: Safeguards against PV reverse polarity, output short circuit, and over-temperature conditions.
