Victron 150/70 VE.Can MPPT Charge Controller 48V HV for Off-grid solar power, Hybrid solar, Telecom and remote

Name: Victron 150/70 VE.Can 48V HV MPPT Charge Controller | Best Price
Brand: victron
SKU: VICTRONS-298-0

Brand victron

Ask about this product

0 /5.0 (0 reviews)

SKU VICTRONS-298-0

Pricing

UGX2,238,500 /Pc

10 available

Minimum order qty 1

QTY

Receive up to 4 quotations from different suppliers of this product

Estimate Shipping Time 1 Days

Inhouse product

Message Seller

Brand victron

Products from this brand

Product spotlights

Highlights: HV configuration. The Victron 150/70 VE.Can MPPT Charge Controller supports low voltage (LV) battery systems from 12V to 48V and is suitable for both single and multi-phase solar installations in Uganda. Its advanced data communication and parallel operation features make it ideal for scalable off-grid and hybrid solar setups.

Brand	Victron	Max Charging Current	150V
Nominal Voltage	12/24/48V Auto Select (36V: manual)	Product Dimensions	185 x 250 x 95mm; 216 x 295 x 103mm
Product Weight	3KG	Communication	VE.Can, VE.Direct and Bluetooth
Efficiency	98	Battery terminals	35mm² / AWG2
Charging Algorithm	multi-stage adaptive (eight preprogrammed algorithms) or user defined algorithm	Humidity	95 %, non-condensing
Max PV Short Circuit Current (per tracker)	50A (max 30A per MC4 conn.)	Programmable Relay	DPST AC rating: 240VAC / 4A DC rating: 4A up to 35VDC, 1A up to 60VDC
Protection	PV reverse polarity / Output short circuit / Over temperature	Protection Category (IP)	IP43 (electronic components), IP22 (connection area)
PV terminals	35mm² / AWG2 (Tr models); Two pairs of MC4 connectors (MC4 models)	Remote On/Off	Yes (2 pole connector)
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2	Self-consumption	Less than 35 mA @ 12V / 20 mA @ 48V
SKU	SM-MPP-VIC-00249	Temperature Compensation Range	-16 mV / -32 mV / -64 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Compare With Similar capacity MPPT Charge Controller

Cash on Delivery Available
Free Shipping

0.0

Average Rating

Verified Reviews

Product Questions

Units In Stock

Freelancers

Verified

Verified Solar Installers for this Product

View All

No freelancers found for this skill.

Description

Specs & details

Overview

HV configuration. The Victron 150/70 VE.Can MPPT Charge Controller is engineered for reliable solar energy management in Uganda’s diverse environments. Designed for low voltage (LV) battery banks (12/24/36/48V), it accommodates both single phase and multi-phase system architectures. The controller features adaptive multi-stage charging, robust protection mechanisms, and advanced data logging for up to 46 days. Integrated VE.Can, VE.Direct, and Bluetooth connectivity enable flexible system monitoring and remote management. Parallel operation capability allows for system expansion, supporting up to 25 units via VE.Can. The unit is built to operate efficiently in harsh indoor, unconditioned spaces, with a wide operating temperature range and high humidity tolerance. Safety and compliance are ensured with EN/IEC 62109-1, UL 1741, and CSA C22.2 certifications.

About this item

SYSTEM TOPOLOGY: HV architecture for compliant solar system design.
MULTI-VOLTAGE SUPPORT: Compatible with 12V, 24V, 36V (manual), and 48V battery banks for flexible system design.
HIGH CHARGE CURRENT: Delivers up to 70A rated charge current for large-scale solar arrays.
ADVANCED DATA COMMUNICATION: Features VE.Can, VE.Direct, and Bluetooth for monitoring and integration.
PARALLEL OPERATION: Supports synchronised parallel operation for scalable installations (up to 25 units via VE.Can).
ROBUST PROTECTION: Includes PV reverse polarity, output short circuit, and over temperature safeguards.
