Victron MPPT 75/10 MPPT Charge Controller 48V for Off-grid solar home, Small commercial solar, Rural electrification

Name: Victron MPPT 75/10 48V MPPT Charge Controller | Best Price Uganda
Brand: victron
SKU: VICTRONS-292-0

Brand victron

Ask about this product

0 /5.0 (0 reviews)

SKU VICTRONS-292-0

Pricing

UGX481,580 /Pc

8 available

Minimum order qty 1

QTY

Receive up to 4 quotations from different suppliers of this product

Estimate Shipping Time 1 Days

Inhouse product

Message Seller

Brand victron

Products from this brand

Product spotlights

Highlights: The Victron MPPT 75/10 is a low voltage (LV), single phase MPPT charge controller designed for 12V or 24V solar systems. It features Bluetooth Smart connectivity for easy monitoring and configuration, making it suitable for off-grid and backup applications in Uganda.

Brand	Victron	Model	MPPT 75/10
Max Charging Current	10	Nominal Voltage	48
Product Dimensions	100 x 113 x 40mm	Product Weight	0,5kg
Communication	VE.Direct (see the data communication white paper on our website)	Efficiency	98
Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)	Absorption Voltage	14,4V / 28,8V (adjustable)
Automatic load disconnect	Yes	Charging Algorithm	multi-stage adaptive
Float Charge Voltage	13,8V / 27,6V (adjustable)	Humidity	95 %, non-condensing
Low voltage load disconnect	11,1V / 22,2V / 44,4V or 11,8V / 23,6V / 47,2V or Battery Life algorithm	Max PV Short Circuit Current (per tracker)	13
Max PV Voltage (DC)	75	Max. continuous load current	15A
Protection	Output short circuit / Over temperature	Protection Category (IP)	IP43 (electronic components), IP22 (connection area)
PV terminals	6mm² / AWG10	Safety	EN/IEC 62109-1, UL 1741, CSA C22.2
Self-consumption	12V: 19 mA 24V: 16	SKU	SM-PWM-VIC-00243
Temperature Compensation Range	-16 mV / °C resp. -32 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Compare With Similar capacity PWM Charge Controllers

Cash on Delivery Available
Free Shipping

0.0

Average Rating

Verified Reviews

Product Questions

Units In Stock

Freelancers

Verified

Verified Solar Installers for this Product

View All

No freelancers found for this skill.

Description

Specs & details

Overview

The Victron MPPT 75/10 MPPT Charge Controller is engineered for reliable solar charging in low voltage (LV), single phase 12V or 24V systems. With ultra-fast Maximum Power Point Tracking (MPPT) technology, it maximizes energy harvest even under fluctuating light conditions, which is common in Uganda’s climate. Integrated Bluetooth Smart allows for wireless setup, monitoring, and firmware updates via mobile devices. The controller supports intelligent battery management with programmable charging algorithms and features a load output to prevent battery over-discharge. Its robust design includes temperature compensation, short circuit protection, and recovery for fully discharged batteries, ensuring dependable operation in demanding environments. The compact form factor and IP43/IP22 protection ratings make it suitable for residential, small commercial, and rural solar installations.

About this item

BLUETOOTH SMART: Built-in wireless connectivity enables remote setup, monitoring, and updates via the VictronConnect app.
ULTRA-FAST MPPT: Advanced tracking algorithm increases solar energy harvest by up to 30% compared to PWM controllers.
LOAD OUTPUT: Integrated load output disconnects to prevent battery over-discharge, supporting battery longevity.
INTELLIGENT BATTERY MANAGEMENT: Adaptive multi-stage charging and Battery Life algorithm optimize battery health.
TEMPERATURE COMPENSATION: Internal sensor adjusts charging voltages based on ambient temperature for safe operation.
FULLY DISCHARGED BATTERY RECOVERY: Automatically initiates charging on deeply discharged batteries, including Li-ion with disconnect.

Product FAQs

The controller supports both lead-acid (flooded, AGM, GEL) and lithium batteries with programmable charging algorithms.

Yes, Bluetooth Smart connectivity allows wireless monitoring and configuration via the VictronConnect app on smartphones or tablets.

No, this model is designed for single phase, low voltage (LV) 12V or 24V systems.

The maximum PV open circuit voltage is 75V, and the maximum PV short circuit current is 13A.

Yes, the integrated load output disconnects loads to prevent battery over-discharge based on preset voltages or the Battery Life algorithm.

Yes, it features a recovery function that initiates charging even if the battery voltage is at zero, including lithium batteries with integrated disconnect.

Yes, it operates reliably in temperatures from -30°C to +60°C and up to 95% non-condensing humidity, making it suitable for Uganda’s conditions.
