Victron 150/70 Solar Inverter PSW 48V HV for Residential solar, Small commercial solar, Telecom and remote
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
victron

Victron 150/70 Solar Inverter PSW 48V HV for Residential solar, Small commercial solar, Telecom and remote

UGX2,791,404
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX60,000Delivery in 7 days1-yr warranty
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX2,791,404
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · manufacturing defects
The warranty is this product's own (1 year). 7-day return window for manufacturing defects. Contact Masrcorp Solar support with your order reference to arrange an exchange or repair. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Battery Voltage
12 / 24 / 36 / 48 V
Rated Charge Current
70 A
Nominal PV Power
4kVA (48V)
Phase
Single Phase
Voltage Class
Low Voltage (LV)
MPPT
Yes
Warranty
1 year
Brand Victron Model 150/70 Solar Inverter PSW 48V HV
Max PV Input Power 1000 W Max Charging Current 70 A
Max PV Open Circuit Voltage 150 V Nominal Voltage 48 V
Product Dimensions Tr models: 185 x 250 x 95 mm; MC4 models: 215 x 250 x 95 mm Product Weight 3 KG
Communication VE.Direct or Bluetooth Efficiency 98 %
Operating Temperature -30 to +60 °C (full rated output up to 40 °C) Battery terminals 35 mm² / AWG2
Battery-connection 35 mm² / AWG2 Certification EN/IEC 62109-1, UL 1741, CSA C22.2
Charge voltage 'equalization' Default setting: 16,2 V / 32,4 V / 48,6 V / 64,8 V (adjustable) Charging Algorithm multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm
Current Rating 70 A Humidity 95 %, non-condensing
Ingress Protection PD3 Max. PV short circuit current 50 A (max 30 A per MC4 conn.)
Maximum output current 30 A (the MC4 connectors are parallel connected to one MPPT tracker) Nominal PV power, 12 V 1000 W
Parallel Operation Yes: up to 10 units can be synchronized with Bluetooth Permissible Altitude 5000m (full rated output up to 2000m)
Programmable Relay DPST AC rating: 240 VAC / 4 A DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC Protection IP43 (electronic components), IP22 (connection area)
PV terminals 35 mm² / AWG2 (Tr models); Two pairs of MC4 connectors (MC4 models) Remote On/Off Yes (2 pole connector)
Safety EN/IEC 62109-1, UL 1741, CSA C22.2 Self Discharge consumption,Less than 35mA @ 12 V / 20mA @ 48 V
Self-consumption Less than 35mA @ 12 V / 20mA @ 48 V SKU 117
Temperature Compensation Range -16 mV / -32 mV / -64 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

HV configuration. The Victron 150/70 Solar Inverter PSW is engineered for reliable performance in Uganda’s diverse energy environments. With a maximum PV input of 4kVA at 48V and support for 12, 24, 36, and 48V battery banks (auto-select), this inverter is suitable for both residential and commercial solar installations requiring low voltage (LV), single phase operation. The integrated MPPT charge controller maximizes solar harvest with up to 98% efficiency, while adaptive multi-stage charging algorithms ensure optimal battery management. Advanced protection features guard against PV reverse polarity, output short circuit, and over-temperature conditions. Data communication is enabled via VE.Direct or Bluetooth, allowing for remote monitoring and configuration. The inverter supports parallel operation of up to 10 units, making it scalable for larger systems. Designed for indoor, unconditioned environments, it meets international safety standards and is suitable for installation up to 2000m altitude at full rated output.

About this item

  • SYSTEM TOPOLOGY: HV architecture for compliant solar system design.
  • MULTI-VOLTAGE BATTERY SUPPORT: Compatible with 12V, 24V, 36V, and 48V battery banks (auto-select; 36V via software tool).
  • HIGH CHARGE CURRENT: Delivers up to 70A rated charge current for efficient battery charging.
  • INTEGRATED MPPT CONTROLLER: Maximizes solar energy harvest with up to 98% conversion efficiency.
  • DATA MONITORING: VE.Direct and Bluetooth connectivity for real-time system monitoring and configuration.
  • PARALLEL OPERATION: Supports synchronization of up to 10 units for scalable installations.

Applications

  • Residential solar power systems (off-grid or hybrid)
  • Small commercial solar installations
  • Telecom and remote site power supply
  • Solar battery charging stations
  • Educational and institutional solar projects
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What battery voltages does the Victron 150/70 support?
The inverter supports 12V, 24V, 36V (via software tool), and 48V battery banks with automatic voltage selection.
Is this inverter suitable for single phase LV systems in Uganda?
Yes, the Victron 150/70 is designed for low voltage (LV), single phase solar installations, making it suitable for most residential and small commercial applications in Uganda.
Can I monitor and configure the inverter remotely?
Yes, the inverter features VE.Direct and Bluetooth connectivity for remote monitoring and configuration using compatible devices.
How many units can be connected in parallel?
Up to 10 Victron 150/70 units can be synchronized in parallel for increased system capacity.
What protection features are included?
The inverter includes protection against PV reverse polarity, output short circuit, and over-temperature conditions.
What is the maximum PV input power at 48V?
The maximum nominal PV input power at 48V is 4kVA (4000W).
Is the inverter suitable for outdoor installation?
No, the Victron 150/70 is designed for indoor, unconditioned environments and should not be installed outdoors.
