Victron MPPT 100/30 30A 12/24V Solar Charge Controller for Off-Grid Solar Systems
⇄ Compare ♡ Save ↗ Share ⬇ Specs (CSV)
victron · MPPT Charge Controllers

Victron MPPT 100/30 30A 12/24V Solar Charge Controller for Off-Grid Solar Systems

UGX592,920
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX17,788Delivery in 7 days1-yr warranty
Christmas on SolarMarket Power for the holidays A gift that keeps the lights on. Pay safely through SolarMarket. Black Friday → Solar for every Christmas plan –Days–Hours–mins
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX592,920
Want another price?Only one shop lists this right now. Send one request and other shops reply with their prices.
More from victronOther victron products on SolarMarket
See All victron →
Victron MPPT 100/50 50A 12/24V Solar Charge Controller for Off-Grid Solar Systems Victron MPPT 100/50 50A 12/24V Solar Charge… UGX771,120 Masrcorp Solar UgandaView → Victron MPPT 75/10 10A 12/24V Solar Charge Controller for Off-Grid Solar Systems Victron MPPT 75/10 10A 12/24V Solar Charge… UGX505,659 Masrcorp Solar UgandaView → Victron MPPT 100/20-48V 20A Solar Charge Controller for Off-Grid Solar Systems, 100V PV Input Victron MPPT 100/20-48V 20A Solar Charge… UGX415,800 Masrcorp Solar UgandaView → Victron MPPT 150/45 45A Solar Charge Controller for Off-Grid Solar Systems, 150V PV Input Victron MPPT 150/45 45A Solar Charge Controller UGX876,960 Masrcorp Solar UgandaView → Victron MPPT 75/15 15A 12/24V Solar Charge Controller for Off-Grid Solar Systems Victron MPPT 75/15 15A 12/24V Solar Charge… UGX344,300 Masrcorp Solar UgandaView → Victron MPPT 150/60 60A Solar Charge Controller for Off-Grid Solar Systems, 150V PV Input Victron MPPT 150/60 60A Solar Charge Controller UGX1,401,840 Masrcorp Solar UgandaView → Victron SmartSolar MPPT 150/70 VE.Can 70A 12/24/48V Solar Charge Controller for Off-Grid Systems, 150V PV, 4000W at 48V, Bluetooth Victron SmartSolar MPPT 150/70 VE.Can 70A… UGX1,682,640 Masrcorp Solar UgandaView → Victron SmartSolar MPPT 250/70 70A Solar Charge Controller for Off-Grid Systems, 250V PV Input Victron SmartSolar MPPT 250/70 70A Solar Charge… UGX2,326,170 Masrcorp Solar UgandaView →
More choice from other shopsSimilar products near this price, sold by other shops on SolarMarket
See All MPPT Charge Controllers →
30A Ajay MPPT Charge Controller 30A Ajay MPPT Charge Controller UGX363,000 AJAY SOLARView → Ajay Solar 60A MPPT Solar Charge Controller Ajay Solar 60A MPPT Solar Charge Controller UGX950,400 AJAY SOLARView → SRNE DM200 20A 12/24V MPPT Solar Street Light Controller with LED Driver, 100V PV, IP67 SRNE DM200 20A 12/24V MPPT Solar Street Light… UGX209,000 Renewable Uganda LimitedView → SRNE 60A MPPT Charge Controller for Off-Grid Solar Systems 100Vdc Open Circuit Voltage 12/24/36/48Vdc Battery (Shiner2460) SRNE 60A MPPT Charge Controller UGX508,200 Masrcorp Solar UgandaView →
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemPick one of each. They go in your cart with this product.
Matched to 24 V
Solar PanelsUGX429,000
BatteryUGX1,879,200
With this product
Technicians who install this
View All
Swipe/scroll to see more →
Key specs
Brand Victron Model MPPT 100/30
Max Charging Current 30A Nominal Voltage 24 V
Product Dimensions 130 x 186 x 70 mm Product Weight 1,3 kg
Communication VE.Direct Efficiency 98%
Operating Temperature -30 to +60°C (full rated output up to 40°C) Absorption Voltage Default setting: 14,4V / 28,8V (adjustable)
Charging Algorithm multi-stage adaptive Humidity 95%, non-condensing
Ingress Protection IP43 (electronic components), IP22 (connection area) Max PV Voltage (DC) 100 V
Max. PV short circuit current 35A Nominal PV power, 12 V 440W
Power terminals 16 mm² / AWG6 Protection IP43 (electronic components), IP22 (connection area)
Safety EN/IEC 62109-1, UL 1741, CSA C22.2 Self-consumption 12V: 30 mA 24V: 20 mA
SKU SM-PWM-VIC-00245 Start Voltage 12
Temperature Compensation Range -16 mV / °C resp. -32 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

The Victron MPPT 100/30 Charge Controller is engineered for reliable solar charging in low voltage (LV), single phase systems operating at 12V or 24V. With a maximum charge current of 30A and support for up to 880W of PV input at 24V, this controller is suitable for residential and small commercial solar setups in Uganda. The unit incorporates adaptive multi-stage charging, temperature compensation, and robust electronic protections. Its VE.Direct communication port enables system monitoring and integration with Victron accessories. The controller is certified to EN/IEC 62109-1, UL 1741, and CSA C22.2 standards, ensuring compliance and safety in diverse installation environments.

About this item

  • MPPT TECHNOLOGY: Tracks maximum power point for optimal solar charging efficiency.
  • VOLTAGE CLASS: Supports low voltage (LV) 12V/24V battery systems with automatic selection.
  • CHARGE CURRENT: Delivers up to 30A rated charge current for medium-sized solar arrays.
  • DATA COMMUNICATION: VE.Direct port for real-time monitoring and system integration.
  • ENVIRONMENTAL PROTECTION: IP43 rating for electronics and IP22 for connection area.
  • SAFETY CERTIFICATIONS: Complies with EN/IEC 62109-1, UL 1741, and CSA C22.2 standards.

Applications

  • Residential solar battery charging (12V/24V)
  • Small commercial solar systems
  • Off-grid and hybrid solar installations
  • Solar-powered water pumping
  • Telecom and remote monitoring sites
Ask Volta about this“Will it run my fridge and pump overnight?”
Chat with Volta
Frequently Asked Questions
What battery types are supported by the Victron MPPT 100/30?
The controller supports both lead-acid and lithium battery chemistries with 12V or 24V nominal voltage.
Is the Victron MPPT 100/30 suitable for three phase systems?
No, this model is designed for single phase, low voltage (LV) systems only.
Can I monitor the controller remotely?
Yes, the VE.Direct port allows for real-time monitoring and integration with Victron accessories.
What is the maximum PV input voltage?
The maximum PV open circuit voltage supported is 100V.
Does the controller support temperature compensation?
Yes, it features automatic temperature compensation for optimal battery charging.
What safety certifications does this controller have?
It is certified to EN/IEC 62109-1, UL 1741, and CSA C22.2 standards.
What is the maximum PV power supported at 24V?
The controller supports up to 880W of nominal PV power at 24V.
