Victron 250/100 Solar Inverter Pure Sinewave 48V for Residential solar, Commercial and, Off-grid and hybrid

Name: Victron 250/100 Solar Inverter Pure Sinewave 48V for Residential solar, Commercial and, Off-grid and hybrid
Brand: victron
SKU: 123
Price: 4504500.00 UGX
Availability: InStock

victron

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: HV configuration. The Victron 250/100 Solar Inverter Pure Sinewave is a low voltage (LV), multi-phase solution supporting 12V, 24V, 36V, and 48V battery systems. Designed for Uganda’s diverse solar needs, it features adaptive MPPT charging and robust protection for reliable off-grid and hybrid installations.

UGX4,504,500

10 available

Minimum order qty 1

QTY

Order on WhatsApp

Compare With Similar capacity this category

Sold by Masrcorp Solar Uganda

Message Seller

Brand victron

Products from this brand

Product Information

Technical specifications

Brand	Victron	Model	250/100
Rated Power	5800	Max PV Input Power	1450 W
Max Charging Current	100 A	Max PV Open Circuit Voltage	250 V
Nominal Voltage	48 V	Product Dimensions	Tr models: 216 x 295 x 103; MC4 models: 246 x 295 x 103
Product Weight	4,5 kg	Communication	VE.Can, VE.Direct and Bluetooth
Efficiency	99 %	Operating Temperature	-30 to +60 °C (full rated output up to 40 °C)
Battery terminals	35mm² / AWG2	Charge voltage 'equalization'	Default setting: 16,2 V / 32,4 V / 48,6 V / 64,8 V (adjustable)
Charging Algorithm	multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm	Chemistry	35mm² / AWG2
Current Rating	100	Float Charge Voltage	12/24/36/48
Humidity	95 %, non-condensing	Ingress Protection	PD3
Max PV Short Circuit Current (per tracker)	70	Max. PV short circuit current	70 A (max 30 A per MC4 conn.)
Maximum output current	30 A (the MC4 connectors are parallel connected to one MPPT tracker)	Nominal PV power, 12 V	1450 W
Peak Current (15s)	100	Permissible Altitude	5000 m (full rated output up to 2000 m)
Programmable Relay	DPST AC rating: 240 VAC / 4 A DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC	Protection	IP43 (electronic components), IP22 (connection area)
PV terminals	Three pairs of MC4 connectors (MC4 models)	Remote On/Off	Yes (2 pole connector)
Safety	EN/IEC 62109-1, UL 1741, CSA C22.2	Safety Standard	EN/IEC 62109-1, UL 1741, CSA C22.2
Self Discharge	consumption,Less than 35 mA @ 12 V / 20 mA @ 48 V	Self-consumption	Less than 35 mA @ 12 V / 20 mA @ 48 V
SKU	123	Temperature Compensation Range	-16 mV / -32 mV / -64 mV / °C

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

HV configuration. The Victron 250/100 Solar Inverter Pure Sinewave is engineered for flexible integration in both residential and commercial solar systems across Uganda. Supporting low voltage (LV) battery banks at 12V, 24V, 36V (manual), and 48V, it accommodates a wide range of system designs and scales. The inverter’s advanced MPPT technology ensures maximum energy harvest from PV arrays up to 5.8kW at 48V, with a rated charge current of 100A. Eight pre-programmed and user-defined charging algorithms, combined with temperature compensation, optimise battery health and performance. The unit is suitable for both single phase and multi-phase

About this item

SYSTEM TOPOLOGY: Low Voltage architecture for compliant solar system design.
MULTI-VOLTAGE SUPPORT: Compatible with 12V, 24V, 36V (manual), and 48V battery systems for flexible system design.
HIGH CHARGE CURRENT: Delivers up to 100A rated charge current, supporting large battery banks and high PV input.
ADVANCED MPPT TECHNOLOGY: Maximises solar energy harvest with adaptive, multi-stage charging algorithms.
ROBUST PROTECTION: Integrated safeguards against PV reverse polarity, output short circuit, and over-temperature conditions.
DATA CONNECTIVITY: Features VE.Can, VE.Direct, and Bluetooth for remote monitoring, configuration, and parallel operation.
