Growatt 3.5kVA Hybrid Inverter for Home and VS Growatt 5kVA 5000W Hybrid Inverter for Home
No image
VS
No image
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | Growatt 3.5kVA Hybrid Inverter for Home and | Growatt 5kVA 5000W Hybrid Inverter for Home |
|---|---|---|
| Overview | ||
| Model | IP20 | IP20 |
| Battery Type | Lithium/Lead-acid | Lithium/Lead-acid |
| Brand | Growatt | Growatt |
| Output | ||
| Surge Power | 7000 VA | 10000 VA |
| Waveform | Pure sine wave | Pure sine wave |
| Rated Power | 3500 VA/ 3500 W | 5000 VA/ 5000 W |
| Battery | ||
| Chemistry | Lead-acid | Lead-acid |
| Max Charging Current | 60 A | 100 A |
| Solar Input | ||
| MPPT Voltage Range | 120 V | 120 V |
| Max PV Input Power | 4500 W | 6000 W |
| Start Voltage | 48 | 48 |
| Short Circuit Current (Isc) | 22 A | 22 A |
| AC Input | ||
| Rated AC Input/Output Active Power (W) | 3500 VA/ 3500 W | 5000 VA/ 5000 W |
| Max. AC Input/Output Apparent Power (VA) | 3500 VA/ 3500 W | 5000 VA/ 5000 W |
| Max AC Input Voltage | 230 Vac | 230 Vac |
| Parallel Capability | Yes, 6 units maximum | Yes, 6 units maximum |
| Transfer Time | 10ms typical, 20ms Max | 10ms typical, 20ms Max |
| Electrical | ||
| Maximum Charge Power | 4500 W kW | 6000 W kW |
| Max. efficiency | 93% | 93% |
| Nominal Voltage | 48 VDC V | 48 VDC V |
| Input Voltage Range | 170-280 Vac (For Personal Computers) ; 90-280 Vac (For Home Appliances) | 170-280 Vac (For Personal Computers) ; 90-280 Vac (For Home Appliances) |
| Current Rating | 80 A | 100 A |
| Protection | ||
| Ingress Protection | IP20 | IP20 |
| Protection | degree, IP20 | degree, IP20 |
| Physical | ||
| Operating Temperature | 0°C - 55° C | 0°C - 55° C |
| Product Weight | 11.5 kg | 12 kg |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | 5% to 95% Relative Humidity(Non-condensing) |
| Storage Temperature | -15°C - 60° C | -15°C - 60° C |
| Compatibility | ||
| Brand Compatibility | Official: , | Official: , |
| Other Specs | ||
| Permissible Altitude | <2000m | <2000m |
Overview
Model
IP20
IP20
Battery Type
Lithium/Lead-acid
Lithium/Lead-acid
Brand
Growatt
Growatt
Output
Surge Power
7000 VA
10000 VA
Waveform
Pure sine wave
Pure sine wave
Rated Power
3500 VA/ 3500 W
5000 VA/ 5000 W
Battery
Chemistry
Lead-acid
Lead-acid
Max Charging Current
60 A
100 A
Solar Input
MPPT Voltage Range
120 V
120 V
Max PV Input Power
4500 W
6000 W
Start Voltage
48
48
Short Circuit Current (Isc)
22 A
22 A
AC Input
Rated AC Input/Output Active Power (W)
3500 VA/ 3500 W
5000 VA/ 5000 W
Max. AC Input/Output Apparent Power (VA)
3500 VA/ 3500 W
5000 VA/ 5000 W
Max AC Input Voltage
230 Vac
230 Vac
Parallel Capability
Yes, 6 units maximum
Yes, 6 units maximum
Transfer Time
10ms typical, 20ms Max
10ms typical, 20ms Max
Electrical
Maximum Charge Power
4500 W kW
6000 W kW
Max. efficiency
93%
93%
Nominal Voltage
48 VDC V
48 VDC V
Input Voltage Range
170-280 Vac (For Personal Computers) ; 90-280 Vac (For Home Appliances)
170-280 Vac (For Personal Computers) ; 90-280 Vac (For Home Appliances)
Current Rating
80 A
100 A
Protection
Ingress Protection
IP20
IP20
Protection
degree, IP20
degree, IP20
Physical
Operating Temperature
0°C - 55° C
0°C - 55° C
Product Weight
11.5 kg
12 kg
Humidity
5% to 95% Relative Humidity(Non-condensing)
5% to 95% Relative Humidity(Non-condensing)
Storage Temperature
-15°C - 60° C
-15°C - 60° C
Compatibility
Brand Compatibility
Official: ,
Official: ,
Other Specs
Permissible Altitude
<2000m
<2000m
Frequently Asked Questions
Key differences from the current specs are: Rated Power (3500 VA/ 3500 W vs 5000 VA/ 5000 W); Max PV Input Power (4500 W vs 6000 W); Max Charging Current (60 A vs 100 A).
Growatt 5kVA 5000W Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output MPPT 120-430VDC Expandable to 6 Units IP20 (SPF-5000-ES) currently leads on more weighted core specs (95/100 vs 5/100). For home backup, also confirm battery voltage match and your expected daily load before purchase.
Current price snapshot on SolarMarket Uganda is Growatt 3.5kVA Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output 120-430VDC MPPT Range Expandable to 6 Units IP20 (SPF-3500-ES): UGX 4,042,500, Growatt 5kVA 5000W Hybrid Inverter for Home and Small Business Backup 48VDC 230VAC Output MPPT 120-430VDC E
Yes. You can request quotations from verified sellers using the RFQ flow: https://solarmarket.ug/rfq/create
