Felicity 6kVA/6000W Hybrid Inverter for Home and VS Felicity IVCM1012 LV 1kW Hybrid Inverter, 105V,
VS
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | Felicity 6kVA/6000W Hybrid Inverter for Home and | Felicity IVCM1012 LV 1kW Hybrid Inverter, 105V, |
|---|---|---|
| Overview | ||
| Model | IVEM6048-II | IVCM1012 LV |
| Battery Type | - | Lithium |
| Brand | Felicity | Felicity |
| Output | ||
| Nominal Output Voltage | 230 Vac+5% Vac | (V), 120V±5% V |
| Nominal Output Frequency | 50+0.3 Hz / 60 Hz±0.3 Hz (Adjustable) Hz | (Hz), 50±0.3 Hz/60 Hz±0.3 Hz (Auto detection) Hz |
| Rated Power | 6000 VA W | 1000 VA/1000 W |
| Waveform | Pure Sine Wave | Pure sine wave |
| AC Output Rated Current | - | 10 A |
| Surge Power | Load >200%, 200ms / Load >150%, 5.5s / Load >120%, 7.5s / Load >105%, 10.5s | - |
| Battery | ||
| Max Charging Current | 100 A | 10 A |
| Chemistry | Lithium | Lithium |
| DC low shut down (adjustable) | - | @ Load < 20% |
| Pass Through Without Battery | Yes | - |
| Charging Algorithm | - | Three stage |
| Solar Input | ||
| PV Start-up Voltage | 95 V | - |
| Start Voltage | - | 23 V |
| Max PV Open Circuit Voltage | 500 V | 105 V |
| MPPT Voltage Range | 90V-450 V | Range (V), 15-90 V |
| Max PV Input Power | 6000 W/95-500V W | 800 W |
| Max PV Input Current | 27 A | 35 A |
| Efficiency (PV to INV) | >95% (Rated R Load, Battery Full Charged) | - |
| AC Input | ||
| Transfer Time | - | 10ms typical (UPS); 20ms typical (Appliances) |
| Max. AC Input/Output Apparent Power (VA) | - | 14 A |
| Input AC Voltage Range | 90~280V Vac | (V), 65-140 Vac V |
| Max AC Input Voltage | 280 Vac | 140 Vac±3V Vac |
| Nominal DC Input Voltage | 48 V | 12 V |
| Parallel Capability | Yes, Up to 12 Units | - |
| Rated AC Input/Output Active Power (W) | - | 1000 W |
| Electrical | ||
| Max. Shorted Current | - | 10 A/1000 W |
| Low voltage load disconnect | - | 40±1 Hz |
| Nominal Voltage | 48 V | 105 V |
| High Line Voltage Disconnect | - | 140 Vac±3V |
| Current Rating | 100 A | 10 A |
| Efficiency | 93 % | - |
| Max. Bypass Overload Current | - | 14 A |
| Max. efficiency | - | 90% |
| Connectivity | ||
| Built-in WiFi | module and charger controller 100 A max, Yes | - |
| Communication | Yes | - |
| Protection | ||
| High DC Input Alarm & Fault | - | 30 V |
| Output Short Circuit Protection | Yes | Yes |
| Overcharge Protection | 5s @ >150% load; 10s @ 105%~150% load | Yes |
| Certification | CE-EMC. IEC 62109-1/2. IEC 63027 | - |
| Physical | ||
| Module Dimensions | - | 422x330x181 mm |
| Storage Temperature | - | -15°C ~60° C |
| Product Dimensions | BKVA/6000 W, 48V, 50/60 Hz mm | 340x248x107mm W |
| Product Weight | 12.5 kg | 5.5 kg |
| Operating Temperature | -10°C~50° C | Range, -10°C ~55° C |
| Package Dimensions | - | 422x330x181mm W |
| Operating Temperature Range Discharge | - | -10°C ~55°C |
| Compatibility | ||
| Brand Compatibility | Not specified | Any Brand |
| Other Specs | ||
| Warranty | 2 Years | - |
| Low DC Input Shut-down Recovery | - | 29 V |
Overview
Model
IVEM6048-II
IVCM1012 LV
Battery Type
-
Lithium
Brand
Felicity
Felicity
Output
Nominal Output Voltage
230 Vac+5% Vac
(V), 120V±5% V
Nominal Output Frequency
50+0.3 Hz / 60 Hz±0.3 Hz (Adjustable) Hz
(Hz), 50±0.3 Hz/60 Hz±0.3 Hz (Auto detection) Hz
Rated Power
6000 VA W
1000 VA/1000 W
Waveform
Pure Sine Wave
Pure sine wave
AC Output Rated Current
-
10 A
Surge Power
Load >200%, 200ms / Load >150%, 5.5s / Load >120%, 7.5s / Load >105%, 10.5s
-
Battery
Max Charging Current
100 A
10 A
Chemistry
Lithium
Lithium
DC low shut down (adjustable)
-
@ Load < 20%
Pass Through Without Battery
Yes
-
Charging Algorithm
-
Three stage
Solar Input
PV Start-up Voltage
95 V
-
Start Voltage
-
23 V
Max PV Open Circuit Voltage
500 V
105 V
MPPT Voltage Range
90V-450 V
Range (V), 15-90 V
Max PV Input Power
6000 W/95-500V W
800 W
Max PV Input Current
27 A
35 A
Efficiency (PV to INV)
>95% (Rated R Load, Battery Full Charged)
-
AC Input
Transfer Time
-
10ms typical (UPS); 20ms typical (Appliances)
Max. AC Input/Output Apparent Power (VA)
-
14 A
Input AC Voltage Range
90~280V Vac
(V), 65-140 Vac V
Max AC Input Voltage
280 Vac
140 Vac±3V Vac
Nominal DC Input Voltage
48 V
12 V
Parallel Capability
Yes, Up to 12 Units
-
Rated AC Input/Output Active Power (W)
-
1000 W
Electrical
Max. Shorted Current
-
10 A/1000 W
Low voltage load disconnect
-
40±1 Hz
Nominal Voltage
48 V
105 V
High Line Voltage Disconnect
-
140 Vac±3V
Current Rating
100 A
10 A
Efficiency
93 %
-
Max. Bypass Overload Current
-
14 A
Max. efficiency
-
90%
Connectivity
Built-in WiFi
module and charger controller 100 A max, Yes
-
Communication
Yes
-
Protection
High DC Input Alarm & Fault
-
30 V
Output Short Circuit Protection
Yes
Yes
Overcharge Protection
5s @ >150% load; 10s @ 105%~150% load
Yes
Certification
CE-EMC. IEC 62109-1/2. IEC 63027
-
Physical
Module Dimensions
-
422x330x181 mm
Storage Temperature
-
-15°C ~60° C
Product Dimensions
BKVA/6000 W, 48V, 50/60 Hz mm
340x248x107mm W
Product Weight
12.5 kg
5.5 kg
Operating Temperature
-10°C~50° C
Range, -10°C ~55° C
Package Dimensions
-
422x330x181mm W
Operating Temperature Range Discharge
-
-10°C ~55°C
Compatibility
Brand Compatibility
Not specified
Any Brand
Other Specs
Warranty
2 Years
-
Low DC Input Shut-down Recovery
-
29 V
Frequently Asked Questions
Key differences from the current specs are: Max PV Input Power (7500 W vs 800 W); Rated Power (6000 VA W vs 1000 VA/1000 W); Max PV Open Circuit Voltage (500 V vs 105 V).
Felicity IVEM6048-II Hybrid Inverter 6kVA 48V, 500V PV, 1 MPPT, Pure Sine Wave, Built-in WiFi, CAN/RS485, for Residential Solar, Small Business, Telecom and ICT currently leads on more weighted core specs (85/100 vs 15/100).
Current price snapshot on SolarMarket Uganda is Felicity IVEM6048-II Hybrid Inverter 6kVA 48V, 500V PV, 1 MPPT, Pure Sine Wave, Built-in WiFi, CAN/RS485, for Residential Solar, Small Business, Telecom and ICT: UGX 1,617,000, 1kW Felicity Hybrid Inverter IVCM1012 LV, 105V, Supports up to 1kW PV Input, For Home backup, S
