TBB · Inverter Chargers

TBB Kinergier Pro CK8.0S 8kVA 6500W 48V Inverter Charger, Pure Sine Wave 230V, 110A AC Charger, 0ms UPS Transfer, Parallel and Three-Phase Ready, for Home and Business Backup

UGX6,504,706
☆☆☆☆☆ No reviews yet ·Questions (0)
App price · Save UGX130,094Delivery in 7 days1-yr warranty
Christmas on SolarMarket Power for the holidays A gift that keeps the lights on. Pay safely through SolarMarket. Black Friday → Solar for every Christmas plan –Days–Hours–mins
Sold by
Masrcorp Solar Uganda ✓
Delivery in 7 days · In stock
UGX6,504,706
Ways to payAll options
Pay NowBank Transfer
Warranty and returns
Warranty
1 year · this product
Returns
7 Days · unused and not installed.
Refund
Replacement only
The warranty is this product's own (1 year). Returns and refunds follow Masrcorp Solar Uganda's signed policy. If the shop doesn't reply to a claim in 48 hours, SolarMarket steps in.
Complete your systemPick one of each. They go in your cart with this product.
Matched to 48 V
Solar PanelsUGX429,000
BatteryUGX3,334,760
Cables, mounting and protectionUGX15,939
With this product
Technicians who install this
Swipe/scroll to see more →
Key specs
Brand TBB Model CK8.0S
Rated Power 8000 VA Max Charging Current 110 A
Nominal Output Voltage 220/230/240 V AC ±2% Nominal Output Frequency 50/60 Hz ±0.1%
Nominal Voltage 42-68 V DC Surge Power 16000 W (10 s)
Product Dimensions 530 x 285 x 185 mm (max) Product Weight 40 kg
Communication CAN bus (parallel, three-phase, remote monitoring); RS485 (GPRS, WLAN optional with Kinergy) Waveform Pure sine wave (THD <2%)
Efficiency 96% Operating Temperature -20 to +60 °C
Absorption Voltage 57.6 V Battery Temperature Sensor Yes (temperature compensation)
Battery Type AGM / GEL / OPzV / Lead-Carbon / Li-ion / Flooded / Traction / TBB SUPER-L Continuous power at 25°C / 40°C 6500 W at 25 °C / 5600 W at 40 °C
Cooling Method Forced fan EMC EN61000-6-2, EN61000-6-4, EN61000-3-11, EN61000-3-12
Float Charge Voltage 55.2 V Humidity (max) 95% without condensation
Ingress Protection IP20 Input AC Voltage Range 175-265 V AC
Inverter Type Inverter charger (transformer based) Max. Continuous AC Passthrough 50 A
Parallel Operation Parallel and three-phase, up to 9 units Permissible Altitude 2000 m
Power Factor 1.0 PowerControl / PowerAssist Power Assist and Power Control
Programmable Relay 2 programmable relays Protection Output short circuit, overload, battery voltage too high/too low, temperature too high, input voltage out of range, input voltage ripple too high, fan block
Remote On/Off Yes Safety Standard EN-IEC 62477-1, CEC (Listed)
SKU SM-INV-TBB-00301 Transfer Time 0 ms (<15 ms in weak AC source mode)
Zero load power (W) 26 W

Notice a wrong or outdated datasheet? Help us fix it.

About this product

Overview

The TBB Kinergier Pro CK8.0S combines an inverter, battery charger and transfer switch in one unit for 48 V battery banks. It gives 8000 VA continuous at 25 °C with 16000 W peak for 10 seconds and switches to battery in 0 ms (under 15 ms in weak AC source mode). Power Assist and Power Control let it work with small generators, and up to 9 units can run in parallel or three-phase.

About this item

  • POWER: 8000 VA / 6500 W continuous at 25 °C, 5600 W at 40 °C, 16000 W peak for 10 s, 300% surge.
  • BATTERY: 48 V nominal, 42-68 V input range; charges AGM, GEL, OPzV, lead-carbon, Li-ion, flooded, traction and TBB SUPER-L batteries.
  • CHARGER: Up to 110 A AC charging; absorption 57.6 V, float 55.2 V, with temperature compensation.
  • AC: 175-265 V AC, 45-65 Hz input; 50 A transfer switch; 220/230/240 V AC ±2% output, 50/60 Hz; two AC outputs (50 A main, 32 A auxiliary).
  • SYSTEM: Power Assist and Power Control for weak generators, feed-in to grid, AC- and DC-coupled PV, AGS generator start; parallel and three-phase up to 9 units.
  • BUILD: Transformer based, 96% max efficiency, forced fan cooling, IP20, 530 x 285 x 185 mm, 40 kg.

Specifications from the TBB Power datasheet 'Inverter Charger Kinergier Pro CK 4KW/5KW/6KW/8KW 230Vac' V1.3 (https://www.tbbrenewable.com/getFile/profile%2Fupload%2F2023%2F05%2F30%2FKinergier_Pro_Inverter_Charger_CK_en_V1.3.pdf), product page https://www.tbbrenewable.com/products/kinergier-pro-ck-inverter-charger
