SRNE 6kW Dual MPPT 48V 100A MPPT VS SRNE 20A MPPT Charge Controller for Off-Grid
VS
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | SRNE 6kW Dual MPPT 48V 100A MPPT | SRNE 20A MPPT Charge Controller for Off-Grid |
|---|---|---|
| Overview | ||
| Brand | SRNE | SRNE |
| Model | RS485 | IP32 |
| Battery Type | USE / FLD / GEL / LI / SLD(default) | Lead-acid / Li-ion / User Defined |
| Battery | ||
| Chemistry | Gel | Lead-acid |
| Solar Input | ||
| Number of MPPT Trackers | 2 | 1 |
| MPPT Tracking Efficiency | 99% | - |
| MPPT Voltage Range | 80 V | (Battery voltage+2V)～45 VDC V |
| Max PV Input Power | 3, 000 W+3, 000 W | 260 W/24V 520 W/24V 800 W/24V 1040 W/24V 1600 W/24V 780 W/36V W |
| Max PV Open Circuit Voltage | 500 VDC+500 VDC V | 60 VDC V |
| Max PV Input Current | 20 A+20 A | - |
| Max. efficiency | 96% | 85%~98%(Correspond load power10%~100%) |
| Electrical | ||
| Rated Power | 6000 W | - |
| Connectivity | ||
| Bluetooth | - | External module BT-2 with mobile app |
| Programmable Relay | NO, C, NC -current limit: DC: 10 A, 30 VDC/ AC: 10 A, 250 Vac | - |
| Communication | Built-in Bluetooth, TTL(connect to WiFi)，RS485 | TTL、RS485 (default) TTL Baud rate 9600kps ，RS485 RJ45 port |
| Physical | ||
| Max Charging Voltage | 120 V | - |
| Cooling Method | Intelligent fan | - |
| Module Dimensions | 440*340*124 MM | - |
| Operating Temperature | - | Range, -35°C~65°C（-31℉～149℉） C |
| Installation | - | Not specified |
| Max Charging Current | 100 A | 20 A |
| Number of Cells | 1~16 units | - |
| Ingress Protection | IP21 | IP32 |
| Warranty | 3 Years | - |
| Start Voltage | up Charging Voltage, 120V | 12 |
| Operating Temperature Range Discharge | - | -35°C~65°C（-31℉～149℉） |
| Current Rating | 100 A | 20 A |
| Safety Standard | Built-in Bluetooth, TTL(connect to WiFi)，RS485 | - |
| Product Weight | 11 kg | 650g(1.43lb) kg |
| Max. continuous load current | - | 10 A |
| Protection | Degree, IP21 | Degree, IP32 |
| Nominal Voltage | 48 V | 24 V |
| Compatibility | ||
| Brand Compatibility | Official: , | Official: , |
Overview
Brand
SRNE
SRNE
Model
RS485
IP32
Battery Type
USE / FLD / GEL / LI / SLD(default)
Lead-acid / Li-ion / User Defined
Battery
Chemistry
Gel
Lead-acid
Solar Input
Number of MPPT Trackers
2
1
MPPT Tracking Efficiency
99%
-
MPPT Voltage Range
80 V
(Battery voltage+2V)～45 VDC V
Max PV Input Power
3, 000 W+3, 000 W
260 W/24V 520 W/24V 800 W/24V 1040 W/24V 1600 W/24V 780 W/36V W
Max PV Open Circuit Voltage
500 VDC+500 VDC V
60 VDC V
Max PV Input Current
20 A+20 A
-
Max. efficiency
96%
85%~98%(Correspond load power10%~100%)
Electrical
Rated Power
6000 W
-
Connectivity
Bluetooth
-
External module BT-2 with mobile app
Programmable Relay
NO, C, NC -current limit: DC: 10 A, 30 VDC/ AC: 10 A, 250 Vac
-
Communication
Built-in Bluetooth, TTL(connect to WiFi)，RS485
TTL、RS485 (default) TTL Baud rate 9600kps ，RS485 RJ45 port
Physical
Max Charging Voltage
120 V
-
Cooling Method
Intelligent fan
-
Module Dimensions
440*340*124 MM
-
Operating Temperature
-
Range, -35°C~65°C（-31℉～149℉） C
Installation
-
Not specified
Max Charging Current
100 A
20 A
Number of Cells
1~16 units
-
Ingress Protection
IP21
IP32
Warranty
3 Years
-
Start Voltage
up Charging Voltage, 120V
12
Operating Temperature Range Discharge
-
-35°C~65°C（-31℉～149℉）
Current Rating
100 A
20 A
Safety Standard
Built-in Bluetooth, TTL(connect to WiFi)，RS485
-
Product Weight
11 kg
650g(1.43lb) kg
Max. continuous load current
-
10 A
Protection
Degree, IP21
Degree, IP32
Nominal Voltage
48 V
24 V
Compatibility
Brand Compatibility
Official: ,
Official: ,
Frequently Asked Questions
Key differences from the current specs are: Max Charging Current (100 A vs 20 A); Nominal Voltage (48 V vs 24 V); Max PV Input Power (3, 000 W+3, 000 W vs 260 W/24V 520 W/24V 800 W/24V 1040 W/24V 1600 W/24V 780 W/36V W).
SRNE 6kW Dual MPPT 48V 100A MPPT Charge Controller for Off-Grid Solar Systems 500VOC+500VOC 80-450V MPPT Range 1-16 Units Parallel Bluetooth RS485 CAN (MF48100N50) currently leads on more weighted core specs (85/100 vs 15/100).
Current price snapshot on SolarMarket Uganda is SRNE 6kW Dual MPPT 48V 100A MPPT Charge Controller for Off-Grid Solar Systems 500VOC+500VOC 80-450V MPPT Range 1-16 Units Parallel Bluetooth RS485 CAN (MF48100N50): UGX 1,670,550, SRNE 20A MPPT Charge Controller for Off-Grid Solar Systems 12/24V 60VOC 260-1600W PV Input I
