Felicity Trex10Klp3G01 10 kW Threephase Hybrid Inv... VS Felicity T-REX-10KLP3G01 Hybrid Inverter 10kVA 40V...
VS
A
Felicity Trex10Klp3G01 10 kW Threephase Hybrid Inv...
Felicity
UGX6,897,000
Offers: 1
View Product
A/B
Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | Felicity Trex10Klp3G01 10 kW Threephase Hybrid Inv... | Felicity T-REX-10KLP3G01 Hybrid Inverter 10kVA 40V... |
|---|---|---|
| Overview | ||
| Model | T‑REX‑10KLP3G01 | T-REX-10KLP3G01 |
| Brand | Felicity | Felicity |
| Output | ||
| Nominal Output Voltage | L1/L2/L3/N/PE, 230/400 Vac | L1/L2/L3/N/PE, 230/400 Vac |
| AC Output Rated Current | 14.5 A | 14.5 A |
| Rated Power | 10000 W | 10000 W |
| Power Factor | >0.99 | >0.99 |
| Nominal Output Frequency | 50/60 Hz | 50/60 Hz |
| Displacement Power Factor | 0.8 (Leading) to 0.8 (Lagging) | 0.8 (Leading) to 0.8 (Lagging) |
| THDi | <3% | <3% |
| Battery | ||
| Chemistry | Li-ion / Lead-acid | - |
| Nominal Voltage | 40V–60V | 720 V |
| Electrical | ||
| Max Charging Current | 200 A | 200 A |
| Max. Shorted Current | 18 A / 18 A | 18 A/18 A |
| Maximum output current | - | 18 A |
| Solar Input | ||
| MPPT Voltage Range | 160V–900 V | 200 V |
| Max PV Input Power | 13000 W (6500 W for Single PV) W | 13000 W (6500 W for Single PV) W |
| Max PV Voltage (DC) | - | 900 V |
| Number of MPPT Trackers | 2 / 1 | 2/1 |
| Start Voltage | 180V | 180V |
| Max PV Open Circuit Voltage | 900 V | - |
| Max PV Input Current | - | 15 A/15 A |
| AC Input | ||
| Max AC Input Voltage | L1/L2/L3/N/PE, 230/400 Vac | - |
| Max. Continuous AC Passthrough | 30 A | 30 A |
| Nominal DC Input Voltage | 2 V | 2 V |
| Anti-Islanding Protection | Integrated | Integrated |
| Grid Regulation | VDE-AR-N 4105 | VDE-AR-N 4105 |
| Grid Regulation VDE-AR | N 4105 | N 4105 |
| Input AC Voltage Range | - | 40V Vac |
| Connectivity | ||
| Communication | RS232 / RS485 | RS232/RS485 |
| Display | LCD + LED | LCD+LED |
| Monitor Module | WiFi / GPRS | WiFi/GPRS |
| Protection | ||
| Ingress Protection | IP65 | IP65 |
| Output Short Circuit Protection | Integrated | Integrated |
| Protection Features | - | Degree, IP65 |
| Safety Regulation IEC 62109-1 / | IEC 62109-1 / -2 | - |
| Insulation Resistor Detection | Integrated | Integrated |
| Overcharge Protection | - | Integrated |
| Protection level | - | IP65 |
| Output Over Current Protection | Integrated | Integrated |
| Physical | ||
| Product Dimensions | 655 × 475 × 266 mm | 655*475*266 mm |
| Installation | - | Style, Wall-mounted |
| Installation Style | Wall-mounted | Wall-mounted |
| Package Dimensions | 792 × 597 × 351 mm | - |
| Cooling Concept | Smart cooling | Smart cooling |
| Product Weight | 38.9 kg | 38.9 kg |
| Operating Temperature | -25°C–60°C, >45°C Derating °C | Range, "-25°C~60°C, >45°C Derating" °C |
| Gross Weight | 47.1KG | - |
| Compatibility | ||
| Brand Compatibility | Official: , | Official: , |
| Other Specs | ||
| Warranty | 10 Years | 10 Years |
Overview
Model
T‑REX‑10KLP3G01
T-REX-10KLP3G01
Brand
Felicity
Felicity
Output
Nominal Output Voltage
L1/L2/L3/N/PE, 230/400 Vac
L1/L2/L3/N/PE, 230/400 Vac
AC Output Rated Current
14.5 A
14.5 A
Rated Power
10000 W
10000 W
Power Factor
>0.99
>0.99
Nominal Output Frequency
50/60 Hz
50/60 Hz
Displacement Power Factor
0.8 (Leading) to 0.8 (Lagging)
0.8 (Leading) to 0.8 (Lagging)
THDi
<3%
<3%
Battery
Chemistry
Li-ion / Lead-acid
-
Nominal Voltage
40V–60V
720 V
Electrical
Max Charging Current
200 A
200 A
Max. Shorted Current
18 A / 18 A
18 A/18 A
Maximum output current
-
18 A
Solar Input
MPPT Voltage Range
160V–900 V
200 V
Max PV Input Power
13000 W (6500 W for Single PV) W
13000 W (6500 W for Single PV) W
Max PV Voltage (DC)
-
900 V
Number of MPPT Trackers
2 / 1
2/1
Start Voltage
180V
180V
Max PV Open Circuit Voltage
900 V
-
Max PV Input Current
-
15 A/15 A
AC Input
Max AC Input Voltage
L1/L2/L3/N/PE, 230/400 Vac
-
Max. Continuous AC Passthrough
30 A
30 A
Nominal DC Input Voltage
2 V
2 V
Anti-Islanding Protection
Integrated
Integrated
Grid Regulation
VDE-AR-N 4105
VDE-AR-N 4105
Grid Regulation VDE-AR
N 4105
N 4105
Input AC Voltage Range
-
40V Vac
Connectivity
Communication
RS232 / RS485
RS232/RS485
Display
LCD + LED
LCD+LED
Monitor Module
WiFi / GPRS
WiFi/GPRS
Protection
Ingress Protection
IP65
IP65
Output Short Circuit Protection
Integrated
Integrated
Protection Features
-
Degree, IP65
Safety Regulation IEC 62109-1 /
IEC 62109-1 / -2
-
Insulation Resistor Detection
Integrated
Integrated
Overcharge Protection
-
Integrated
Protection level
-
IP65
Output Over Current Protection
Integrated
Integrated
Physical
Product Dimensions
655 × 475 × 266 mm
655*475*266 mm
Installation
-
Style, Wall-mounted
Installation Style
Wall-mounted
Wall-mounted
Package Dimensions
792 × 597 × 351 mm
-
Cooling Concept
Smart cooling
Smart cooling
Product Weight
38.9 kg
38.9 kg
Operating Temperature
-25°C–60°C, >45°C Derating °C
Range, "-25°C~60°C, >45°C Derating" °C
Gross Weight
47.1KG
-
Compatibility
Brand Compatibility
Official: ,
Official: ,
Other Specs
Warranty
10 Years
10 Years
Frequently Asked Questions
Key differences from the current specs are: MPPT Voltage Range (160V–900 V vs 200 V); Nominal Voltage (40V–60V vs 720 V); Rated Power (10000 W VA vs 10000 W).
Felicity T-REX-10KLP3G01 Hybrid Inverter 10kVA 40V for Residential solar, Commercial and, Mini-grid and rural currently leads on more weighted core specs (100/100 vs 0/100). For home backup, also confirm battery voltage match and your expected daily load before purchase.
Current price snapshot on SolarMarket Uganda is Felicity T‑REX‑10KLP3G01 10 kW Three‑Phase Hybrid Inverter – Smart, High-Efficiency Energy Hub: UGX 6,897,000, Felicity T-REX-10KLP3G01 Hybrid Inverter 10kVA 40V for Residential solar, Commercial and, Mini-grid and rural: varies. Final price depends on seller offer and av
Yes. You can request quotations from verified sellers using the RFQ flow: https://solarmarket.ug/rfq/create
