Cworth 420W MONO TOPCon Solar Panel for Residential and Commercial Solar Backup 22.3% Efficiency 31.4V Vmp 34.8V Voc 1000/1500VDC System Voltage IP68 Junction Box 12-Year Product Warranty (CE-420W)

Name: Cworth 420W MONO TOPCon Solar Panel for Residential and Commercial Solar Backup 22.3% Efficiency 31.4V Vmp 34.8V Voc 1000/1500VDC System Voltage IP68 Junction Box 12-Year Product Warranty (CE-420W)
Brand: Cworth
SKU: SM-CAT-CWO-00878
Price: 379500.00 UGX
Availability: InStock

Cworth

0 out of 5 | 0 Ratings | Q&A

About this item

Product spotlights

Highlights: Cworth CE-420W is a solar panel in Uganda. Key datasheet highlights include Curves (420W)Isc,Voc,Pmax: — —lv —P-v 180 ;—; Voltage (V): 20 -50 -25 0 25 50 75 100; Cell Temperature (°C): Cell Type MONO TOPCon 182x182mm. Use the published limits for sizing, compatibility checks, and compliant installation planning

UGX363,000

Variation

100 available

Minimum order qty 1

QTY

Order on WhatsApp

Selected Product Summery

Cworth 420W MONO TOPCon Solar Panel for Residential and Commercial Solar Backup 22.3% Efficiency 31.4V Vmp 34.8V Voc 100... -

Compare With Similar capacity Solar Panels

Sold by Cworth Energy

Message Seller

Brand Cworth

Products from this brand

Product Information

Technical specifications

Brand	Cworth	Model	IP68
Rated Power	420	Max PV Open Circuit Voltage	— —lv —P-v 180 ;—
Nominal Voltage	1000/1500VDC (IEC)	Product Dimensions	1956x992x30mm
Product Weight	19 KG	Efficiency	22.3%
Operating Temperature	-40°C~+85°C	Cell Type	MONO TOPCon 182x182mm
Chemistry	MONO TOPCon	Color Temperature	Cell Type MONO TOPCon 182x182mm
Current Rating	13.38	Frame	Anodized Aluminium Alloy
Front Glass	3.2mm, Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass	Junction Box (IP Rating)	IP68 Rated
Max. PV short circuit current	— —lv —P-v 180 ;—	Maximum input voltage	31.4V
Maximum output current	13.38A	Maximum Power (Pmax)	— —lv —P-v 180 ;—
Maximum Series Fuse Rating	30A	NOCT	Irradiance 800W/m², Ambient Temperature 20°C, AM=1.5, Wind Speed 1m/s
Number of Cells	100 (10x10)	Power Tolerance	0~+3%
Short-circuit Current (Isc)	14.18A	SKU	SM-CAT-CWO-00878
Start Voltage	20 -50 -25 0 25 50 75 100	Temperature Coefficient of Voc	-0.35%/°C

Notice a wrong or outdated datasheet? Help us fix it.

Freelancers

Verified

Verified Solar Installers for this Product

View All

Francis Ekapuloni

Professional Solar Expert

Kampala

Solar Installation Solar Energy Audits

View Profile

ETIENE MAATE

ElectroMechanical Engineer

Kampala

Project Management Solar Water heater Solar System Design

View Profile

Tamale Muhamad

Expert Solar Systems Designer & Installer – Powering Your Future!

Kampala

Solar Installation Solar Panel Cleaning Solar Water heater

View Profile

Ndawula Muhamadi

Hybrid Solar Wholesale Supplier & Installer Expert

Masaka

Solar Installation Solar System Design Solar Energy Audits

View Profile

Okitwi Francis

Certified solar technician based in Tororo

Tororo

Solar Installation Inverter Setup Solar System Design

View Profile

Osama Mathew

Solar | water pumps | Backup systems

Kampala

Lighting Troubleshooting CAD Design

View Profile

ANITA

Solar system installation

Kampala

Electrical Repairs Appliance Repair Solar Installation

View Profile

Kizito Vincent

I am a technician dealing in hydro and solar power, security systems, networking...

Kampala

IT Support Electrical Repairs Battery Wiring

View Profile

Kibozeeyi John

Skilled Solar Installer – Expertise in Felicity, CWorth, & other quality brands

Kampala

Solar Installation Solar Panel Cleaning Solar System Design

View Profile

WASSWA Emmy

Solar installer

Bugiri

Electrical Repairs Solar System Design Electrical Installation

View Profile

Swipe/scroll to see more →

Description

Specs & details

Overview

Cworth CE-420W is a solar panel for Uganda operating conditions. It is suitable for Residential rooftop, Commercial, Grid-tied solar power, Off-grid solar home. Buyers should also confirm Curves (420W)Isc,Voc,Pmax: — —lv —P-v 180 ;—; Voltage (V): 20 -50 -25 0 25 50 75 100; Cell Temperature (°C): Cell Type MONO TOPCon 182x182mm; Weight: 19kg~20kg, verified seller pricing, warranty terms, and installer compatibility before ordering

About this item

HIGH EFFICIENCY MONO TOPCon CELLS: Uses 182x182mm MONO TOPCon cells to achieve a module efficiency of 22.3% and a maximum power output of 420W with a positive tolerance of 0 to +5W.
DURABLE CONSTRUCTION: Features a 3.2mm tempered glass front sheet with anti-reflection coating and an anodized aluminium alloy frame for long-term outdoor use in Uganda.
IP68 JUNCTION BOX: The junction box is rated IP68, providing protection against dust ingress and continuous immersion in water, suitable for harsh environmental conditions.
HIGH SYSTEM VOLTAGE CAPABILITY: Rated for a maximum system voltage of 1000/1500VDC (IEC), allowing flexible series configuration for both residential and commercial arrays.
PROVEN MECHANICAL LOAD RESISTANCE: Certified to withstand wind loads of 2400 Pascal and snow loads of 5400 Pascal, ensuring structural reliability under extreme weather.
COMPREHENSIVE WARRANTY COVERAGE: Backed by a 12-year product warranty and a 25-year linear power output warranty with annual degradation of 0.35% per year.

What's Included

1x Cworth CE-420W MONO TOPCon Solar Panel
1x IP68 Junction Box with pre-attached cables
1x Warranty Card

Applications

Residential rooftop solar systems
Commercial and industrial solar installations
Grid-tied solar power plants
Off-grid solar home systems
Solar water pumping systems
Solar backup for small businesses
