Specifications Comparison
Spec keys are preserved from both products. We never remove a key just because the other product has no value yet.
| Feature | - | DEYE 35kW Three Phase High Voltage Hybrid |
|---|---|---|
| Overview | ||
| Model | - | SG01HP3-EU-BM3 |
| Inverter Type | - | Non-Isolated |
| Brand | - | DEYE |
| Battery Type | - | Lithium-ion |
| Output | ||
| Rated Power | - | 35000 W |
| AC Output Rated Current | - | 53.1/50.8 A |
| Power Factor | - | 0.8 leading to 0.8 lagging |
| Other Specs | ||
| Number of Battery Modules | - | 2 |
| Permissible Altitude | - | 0-100% |
| Solar Input | ||
| Max PV Input Power | - | 70000 W |
| MPPT Voltage Range | - | 150-850 V |
| PV Start-up Voltage | - | 180 V |
| Start Voltage | - | up Voltage (V), 180 V |
| Short Circuit Current (Isc) | - | 50+50 |
| Max PV Input Current | - | 36+36+36 A |
| MPPT Tracking Efficiency | - | >99% |
| Number of MPPT Trackers | 1 | 3/2+2+2 |
| AC Input | ||
| Max AC Input Voltage | - | 1000 V |
| Max. AC Input/Output Apparent Power (VA) | - | 38500 |
| Input AC Voltage Range | - | 220/380V, 230/400V 0.85Un-1.1Un V |
| Max. Continuous AC Passthrough | - | 200 A |
| Rated AC Input/Output Active Power (W) | - | 35000 W |
| Electrical | ||
| Surge Power | - | grid)(W), "1.5 times of rated power, 10s" W |
| Over Voltage Category | - | OVC II(DC), OVC III(AC) |
| Max. efficiency | - | 97.60% |
| Nominal Voltage | - | 1000 V |
| Chemistry | - | Lithium |
| Current Rating | - | 53.1 A |
| DC Injection Current | - | <0.5% In |
| Connectivity | ||
| Monitor Module | - | GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| Communication | - | RS485/RS232/CAN |
| Physical | ||
| Product Dimensions | - | 527×894×294 (Excluding Connectors and Brackets) MM |
| Module Dimensions | - | 527×894×294 MM |
| Max Charging Current | - | t (A), 50+50 A |
| Product Weight | - | 80 kg |
| Operating Temperature Range Discharge | - | -40 to +60℃, >45℃ Derating |
| Protection | - | TYPE II(DC), TYPE II(AC) |
| Warranty | - | 5 Years/10 Years |
| Operating Temperature | - | Range (℃), "-40 to +60℃, >45℃ Derating" C |
| Junction Box (IP Rating) | - | IP 65 IP |
| Compatibility | ||
| Brand Compatibility | Not specified | Official: , |
Overview
Model
-
SG01HP3-EU-BM3
Inverter Type
-
Non-Isolated
Brand
-
DEYE
Battery Type
-
Lithium-ion
Output
Rated Power
-
35000 W
AC Output Rated Current
-
53.1/50.8 A
Power Factor
-
0.8 leading to 0.8 lagging
Other Specs
Number of Battery Modules
-
2
Permissible Altitude
-
0-100%
Solar Input
Max PV Input Power
-
70000 W
MPPT Voltage Range
-
150-850 V
PV Start-up Voltage
-
180 V
Start Voltage
-
up Voltage (V), 180 V
Short Circuit Current (Isc)
-
50+50
Max PV Input Current
-
36+36+36 A
MPPT Tracking Efficiency
-
>99%
Number of MPPT Trackers
1
3/2+2+2
AC Input
Max AC Input Voltage
-
1000 V
Max. AC Input/Output Apparent Power (VA)
-
38500
Input AC Voltage Range
-
220/380V, 230/400V 0.85Un-1.1Un V
Max. Continuous AC Passthrough
-
200 A
Rated AC Input/Output Active Power (W)
-
35000 W
Electrical
Surge Power
-
grid)(W), "1.5 times of rated power, 10s" W
Over Voltage Category
-
OVC II(DC), OVC III(AC)
Max. efficiency
-
97.60%
Nominal Voltage
-
1000 V
Chemistry
-
Lithium
Current Rating
-
53.1 A
DC Injection Current
-
<0.5% In
Connectivity
Monitor Module
-
GPRS/WIFI/Bluetooth/4G/LAN(optional)
Communication
-
RS485/RS232/CAN
Physical
Product Dimensions
-
527×894×294 (Excluding Connectors and Brackets) MM
Module Dimensions
-
527×894×294 MM
Max Charging Current
-
t (A), 50+50 A
Product Weight
-
80 kg
Operating Temperature Range Discharge
-
-40 to +60℃, >45℃ Derating
Protection
-
TYPE II(DC), TYPE II(AC)
Warranty
-
5 Years/10 Years
Operating Temperature
-
Range (℃), "-40 to +60℃, >45℃ Derating" C
Junction Box (IP Rating)
-
IP 65 IP
Compatibility
Brand Compatibility
Not specified
Official: ,
