Pedrollo 6Sr Submersible Borehole Pump High Flow 6 Stainless Steel Pump For Deep Wells Irrigation Sb Innovations Uganda
| Brand | Pedrollo | Model | 6SR |
|---|---|---|---|
| Nominal Voltage | 400 V three-phase, 50 Hz | Flow Rate | up to 60 m3/h (1000 l/min) (range) |
| Max Head | up to 390 m (range) | Pump Type | 6 inch multistage submersible borehole pump with three-phase motor (6PD or 6PSR) |
| SKU | SM-SUB-PED-00444 |
Notice a wrong or outdated datasheet? Help us fix it.
The Pedrollo 6SR Series is a high-performance line of 6-inch submersible borehole pumps engineered for demanding water applications in Uganda’s domestic, agricultural, and commercial sectors. Designed with abrasion-resistant materials, the 6SR pumps deliver consistent water output even in wells with sand content up to 100 g/m³6SR_EN-datasheet_50Hz.
With flow rates up to 1000 L/min (60 m³/h) and heads reaching 390 meters, these pumps are perfect for deep wells, irrigation farms, commercial water transfer, fire-fighting systems, and pressure boosting.
All models are powered by three-phase 400V motors, available in oil-filled (6PD) or water-filled (6PSR) versions, and come pre-assembled with a 4-meter cable.
⚙️ Key Features & Benefits
✅ Wide Range of Power & Flow
-
Available from 4kW to 30kW
-
Handles flows from 200 to 1000 L/min
-
Maximum head: up to 390m6SR_EN-datasheet_50Hz
✅ Sand-Tolerant Hydraulic Design
Floating impellers and sand-resistant bearings allow safe operation in sandy boreholes (up to 100 g/m³).
✅ Heavy-Duty Stainless Steel Construction
Pump body, shaft, filter, sleeve, and check valve all made from AISI 304/316 stainless steel for corrosion resistance and long life6SR_EN-datasheet_50Hz.
✅ Flexible Mounting Options
Supports vertical installation up to 200m depth, and limited horizontal use for tanks or open reservoirs (up to 11 kW / 12 stages)6SR_EN-datasheet_50Hz.
✅ Energy Efficient – MEI ≥ 0.40
Optimized hydraulic design reduces energy consumption and runtime for large pumping systems6SR_EN-datasheet_50Hz.
✅ Cooling Jacket Ready (Optional)
For river/lake/reservoir use, supports optional cooling jackets to maintain safe motor temperature.
✅ Ready-to-Install with 4m Cable
Minimizes installer setup time.
? Applications – Ideal For:
-
? Deep Borehole Water Supply for Homes & Estates
-
? Large-Scale Irrigation for Commercial Farms
-
? Overhead Tank Filling from 60m–300m Depths
-
? Fire-Fighting & Booster Systems in Buildings
-
? Livestock & Poultry Watering Systems
-
? Industrial & Rural Water Transfer Solutions
? Top Performing Models
| Model | Power (kW/HP) | Max Flow (L/min) | Max Head (m) |
|---|---|---|---|
| 6SR 12/28 | 15 kW / 20 HP | 330 L/min | 390 m |
| 6SR 18/22 | 18.5 kW / 25 HP | 450 L/min | 298 m |
| 6SR 27/27 | 30 kW / 40 HP | 600 L/min | 367 m |
| 6SR 36/22 | 22 kW / 30 HP | 800 L/min | 274 m |
| 6SR 44/25 | 30 kW / 40 HP | 1000 L/min | 310 m |
? Sold by SB Innovations Uganda on Solar Market Uganda
✅ Authentic Pedrollo Pumps
✅ Bulk pricing for contractors & installers
✅ Technical support & delivery across Uganda
